125V 20A Slim GFCI Electrical Outlet Self Test Grounding Fault Interruptor

Product Description:

A GFCI receptacle is an abbreviation for "Ground Fault Circuit Interrupter." In Chinese, it's called a ground fault current leakage protector and is a specialized protective device for the North American market. It operates at a voltage of 102VAC-132VAC and a frequency of 60HZ, with an operating temperature range of -35°C to 66°C. It has a trip time of less than 25ms and a trip current of 4-6mA. It must be UL or ETL certified. It's an electrical product that integrates ground fault protection, over-voltage protection, under-voltage protection, and switching functions for enhanced safety.

The working principle of a GFCI is as follows: When there's an equipment leakage or an electric shock to a person, some current flows into the ground. If the current flowing through the hot wire and the neutral wire becomes unequal (under normal conditions, they are equal), the GFCI monitors this current difference. As soon as this difference exceeds 6mA, it instantly cuts off the power supply within 0.025 seconds, thereby ensuring the safety of people and property.

Technical Parameters:

Applications:

GFCI socket with light switch can be used in various occasions and scenarios due to its safety features and convenience. Here are some recommended application areas:

1. Residential Buildings: Install the GFCI socket with light switch in bathrooms, kitchens, and outdoor areas to protect against electrical shocks and potential hazards.

2. Commercial Establishments: Ideal for use in restaurants, hotels, and offices where electrical appliances are frequently used, ensuring safety for employees and customers.

3. Educational Institutions: Use the GFCI socket with light switch in classrooms, labs, and dormitories to prevent electrical accidents and create a secure learning environment.

4. Healthcare Facilities: Critical in hospitals, clinics, and laboratories to safeguard patients, medical equipment, and staff from electrical faults.

5. Industrial Sites: Essential for factories, warehouses, and production facilities to maintain a reliable power supply and protect machinery from damage.

6. Outdoor Spaces: The weather Resistant design is perfect for gardens, patios, and swimming pools where water exposure is a concern, ensuring electrical safety in all weather conditions.

By incorporating the KG-S20T GFCI socket with light switch, users can enjoy peace of mind knowing that their electrical connections are secure and protected against potential risks.
